Oil Hose is manufactured from a special polymer compound that provides strong resistance to oil and light petroleum products. Unlike traditional rubber hoses, it does not crack, harden, or age, ensuring long-lasting durability and cost-effectiveness. The hose is reinforced with a rigid spiral structure inside a flexible wall, offering both strength and easy handling during use.
| nominal Size | diameter | inside Diameter | outside Diameter | bending Radius | working Pressure | bursting Pressure | standard Lengths |
|---|---|---|---|---|---|---|---|
| 1 | 25 | 25.4 ± 0.5 | 31.5 ± 1.0 | 48 | 8 | 22 | 30 |
| 1 1/4 | 30 | 31.8 ± 0.5 | 39.0 ± 1.0 | 68 | 7 | 21 | 30 |
| 1 1/2 | 40 | 38.1 ± 0.5 | 46.4 ± 1.0 | 70 | 5.5 | 18 | 30 |
| 2 | 50 | 50.8 ± 0.5 | 60.8 ± 1.5 | 100 | 4.5 | 18 | 30 |
| 2 1/2 | 65 | 63.5 ± 1.0 | 74.5 ± 1.5 | 120 | 4.5 | 14 | 30 |
| 3 | 75 | 76.2 ± 1.0 | 87.2 ± 1.5 | 155 | 4.5 | 14 | 30 |
| 4 | 100 | 101.2 ± 1.0 | 114.2 ± 1.5 | 213 | 4 | 14 | 15/18/30 |
