Mining Hose is designed for the pumping and transfer of abrasive slurry under both pressure and vacuum conditions. It offers excellent abrasion resistance, high tensile strength, and remains flexible for easy installation even in tight spaces. A reliable choice for demanding mining and slurry handling operations.
| nominal Size | diameter | inside Diameter | outside Diameter | bending Radius | working Pressure | bursting Pressure | standard Length |
|---|---|---|---|---|---|---|---|
| 1" | 25 mm | 25.4 ± 0.5 mm | 31.5 ± 1.0 mm | 48 mm | 8.0 kg/cm² | 22.0 kg/cm² | 30 mtrs |
| 1¼" | 30 mm | 31.8 ± 0.5 mm | 39.0 ± 1.0 mm | 68 mm | 7.0 kg/cm² | 21.0 kg/cm² | 30 mtrs |
| 1½" | 40 mm | 38.1 ± 0.5 mm | 46.4 ± 1.0 mm | 70 mm | 5.5 kg/cm² | 18.0 kg/cm² | 30 mtrs |
| 2" | 50 mm | 50.8 ± 0.5 mm | 60.8 ± 1.5 mm | 100 mm | 4.5 kg/cm² | 18.0 kg/cm² | 30 mtrs |
| 2½" | 65 mm | 63.5 ± 1.0 mm | 74.5 ± 1.5 mm | 120 mm | 4.5 kg/cm² | 18.0 kg/cm² | 30 mtrs |
| 3" | 75 mm | 76.2 ± 1.0 mm | 87.2 ± 1.5 mm | 155 mm | 4.5 kg/cm² | 18.0 kg/cm² | 30 mtrs |
| 4" | 100 mm | 101.2 ± 1.0 mm | 114.2 ± 1.5 mm | 213 mm | 4.0 kg/cm² | 14.0 kg/cm² | 15/18/30 mtrs |
